AutoCAD Mechanical Training

AutoCAD Mechanical includes the very best of AutoCAD along with industry-specific libraries of parts and tools for mechanical engineering, making it a must-learn application for anyone involved in the design and construction of machinery. AutoCAD Mechanical is one of the toolsets available in one AutoCAD. This course covers the basics of the AutoCAD Mechanical 2020 user interface and leads you step-by-step through producing precise, measured mechanical engineering drawings and designs.

  • Navigating the AutoCAD Mechanical 2020 interface
  • Managing layers and object properties
  • Structuring, reusing, and editing your mechanical data
  • Creating key geometry
  • Adding centerlines and holes
  • Manipulating geometry
  • Inserting parts with part generators
  • Creating drawing sheets
  • Annotating parts
  • Placing dimensions
  • Creating a bill of materials and parts list
  • Calculating design factors
  • Using existing drawing data
  • Creating a default standard template

AutoDesk Authorised Training Center (ATC) in Singapore

Certificate

All participants will receive a Certificate of Completion from Tertiary Courses after achieved at least 75% attendance.

Funding and Grant Applications

Click the links below to apply. Note that you need to register the course first.

For Singaporeans: SkillsFuture Credit

For Company: WSG Absentee Payroll

Course Code: CRS-N-0050382

Course Booking

$498.00 (GST-exclusive)
$532.86(GST-inclusive)

Course Date

* Required Fields

Course Cancellation/Reschedule Policy

We reserve the right to cancel or re-schedule the course due to unforeseen circumstances. If the course is cancelled, we will refund 100% to participants.
Note the venue of the training is subject to changes due to class size and availability of the classroom.
Note the minimal class size to start a class is 3 Pax.


Course Details

Day 1

Module 1. Explore the AutoCAD Mechanical User Interface

  • Explore the AutoCAD Mechanical user Interface
  • Use the AutoCAD Mechanical ribbon
  • The enhanced shortcut menu
  • The Mechanical Browser
  • Drafting Settings dialog box
  • Quick Access Toolbar (QAT)

Module 2. Object Property and Layer Management

  • Property management
  • Automatic property management
  • Layer control and controlling the layer display
  • Use geometry on layers

Module 3. Organize Your Mechanical Drawing

  • Draw creation workflows
  • Structure your mechanical data in drawings
  • Create a mechanical drawing using structure
  • Reuse structured data
  • Edit structured data

Module 4. Create Your Key Geometry

  • Create geometry using the core design tools
  • Configure and activate Power Snaps
  • Add centerlines and holes
  • Add and use construction lines
  • Design with lines
  • Add holes and slots

Module 5. Manipulate Mechanical Geometry

  • Work with basic editing tools
  • Use power commands
  • Create and edit associative hides
  • Create and edit associative hides with structure

Module 6. Use Mechanical Part Generators

  • Insert standard parts
  • Notate standard parts
  • Use the Content Libraries palette
  • Design chains and belts
  • Place a shaft in an assembly
  • Insert springs into a drawing

Day 2

Module 7. Create Mechanical Drawing Sheets

  • Create viewports and details in layouts
  • Create drawing sheets in model space
  • Use annotation views in structure
  • Insert title blocks and borders

Module 8. Work with Dimensions and Annotation

  • Annotate parts
  • Add different power dimensions
  • Place multiple dimensions
  • Edit dimensions
  • Add hole charts and fits lists
  • Create a revision list

Module 9. Bill of Materials, Parts Lists, and Balloons

  • Create part references
  • Create and edit a bill of materials
  • Create and edit a bill of materials with structure

Module 10. Use Design Calculations

  • Calculate moments of inertia
  • Calculate the deflection line
  • Calculate shaft strength
  • Calculate FEA stresses

Module 11. Leverage Existing Drawing Data

  • Demonstrate mechanical content in an AutoCAD Mechanical DWG
  • Demonstrate mechanical content in an AutoCAD DWG
  • Create views associated with an Inventor model

Module 12. Mechanical Options (CAD Manager)

  • Create and settle a default standard template
  • Configure layers and object properties
  • Set annotation properties
  • Configure BOM, parts list, and balloons

Course Admin

Prerequisite

No prior knowledge on AutoCAD is required;

Software Requirement

Participants need to bring their laptops with Autodesk software installed on their laptops for the training. If participant does not have the laptop and software, we can provide spare laptops with licensed Autodesk software

Who Should Attend

  • Mechanical Engineers
  • Mechanical Designers

Trainers

AutoCAD Certified ProfessionalJyoti Chopra has professional experience in teaching Autocad, 3DsMax and Revit in a recognized teaching institute. She has been a AutoCad teacher with 4 years of experience in teaching designing principles and introducing students to designing softwares. She hhas experience as Architectural Designer performing design, simulation and drafting of various residential and landscape projects in Singapore. Her skillsets are AutoCAD, Revit, 3Ds Max. Adobe Photoshop and Furniture Design, Graphics, Sketching and 2D/3D Simulation. She is also Autodesk Certified Professional (Autocad)

AutoCAD Certified ProfessionalGoh Hao Ming graduated from the National University of Singapore with a strong interest in 3D modelling and prototyping. He has used 3D modelling software extensively in his work and education and is a AutoCAD Certified Professional and is familiar with AutoCAD’s programing interface, VisualLisp for improving workflow and efficiency of work.

AutoCAD TrainerSivamoorthy Kanagalingam’s scope of work focuses on numerical analysis and uses Fluent for flow and thermal analysis. Computational fluid dynamics has prominent applications in the fields of Aerospace, Automobile, Mechanical, Oil and Gas, Civil, Urban development, Environment etc. Siva has been working on CFD since 2010 and completed many projects in Aerospace and Mechanical sectors. He is still an active user of Ansys CFX, Fluent, ICEM CFD, OpenFOAM and currently involved in multiphase, dynamic analysis.

Sivamoorthy Kanagalingam is a passionate Aerospace Engineer with interest and experience in Aerodynamics, Fluid Dynamics, Fluid Structure Interaction, Computational Fluid Dynamics

AutoCAD TrainerJason is a freelance designer with a big passion for creating 3D Interactive walk-through and have 4 years of experience in Interior design industry with a large spectrum of skills.My passion for design and visualization has always pushed me to keep learning and constantly trying to improve my Skills.I come equipped with a huge arsenal of knowledge and experience with an array of software, technologies and methodologies.

He pride himself on being able to learn, master and innovate using nearly any software handed to him. From Blueprints in UE4 to data driven modelling applications like Autocad to 3D modelling packages like 3Ds Max and Maya. I revel in the challenge of mastering the unknown and making it work.

AutoCAD trainerBernadette graduated from the University of Melbourne, specialising in Architecture. She has a variety of soft skills from her vast exposure from designing to the building construction discipline. Since returning to Singapore in 2015, she too has worked in various fields aside from her full-time job as an Architectural Assistant such as teaching young children arts and crafts as well as educating professional working adults in their soft skills development. She has recently returned for her studies at the National University of Singapore in pursue of her further studies.

Autocad trainer Charlie CHANG CHENG CHIEH graduated from Nanyang Academic of Fine Arts last mid-year. Under the major of Interior & Exhibition Design. Currently, He has been working in an architectural firm as an interior designer. He is familiar with AutoDesk software, as He used them both in school and work.

AutoCAD TrainerSingaram is a Year 4 Aerospace Engineering student at Nanyang Technological University who has experience teaching Solidworks and has done a water sampling machine assembly and an Arduino shield design. He is currently designing an airplane. He is familiar with other design softwares including Autodesk Fusion 360 and Autodesk 123D Design.

He has experience in Raspberry Pi programming as well.

CAD TrainerRuban Sundara Raj is is a Versatile Problem-solver with vast experience in design and development of, mechanical and electronics products and software application.

He has more over 2 and half years of experience in design and development of veterinary tissue sampling equipment, RFID animal and management tags, PCBA enclosures and conveyor systems. In addition to above stated He has experience in firmware development and Big data analytics using python, computer and android application development using Java

His is familiar with design tools such as SolidWorks, Autodesk Inventor and AutoCAD.

AutoCAD TrainerKoh Hui Min has extensive experience in designing, developing and managing for radio-frequency identification tag, production fixture and inventory management. In addition, He is proficient in using software, SolidWorks and working knowledge in using AutoCAD and Creo

Graphics DesignerBelinda graduated from Nanyang Academy of Fine Arts (NAFA) in 2017 with a diploma in Furniture & Spatial Design. With 3 years of training in software skills , mainly Photoshop , Illustrator , Rhinoceros , Inventor ,T spline, Autocad and Vray. Belinda works with softer and rounder forms that are more challenging to create . Also more towards graphic design in Photoshop and Illustrator for most occasions.
